Marshal

Details

Category: Marshal

Last Updated: 02 April 2023

Marshal API has some breaking changes starting with 2023.3.28. Units have been renamed, Marshal Options are now available via a global variable, and plugins require one less reference. Read on to see the changes.

The replacements can be seen demonstrated in this commit on GitHub.

Unit Name Mapping

These units were renamed as part of refactoring.
(replace ZZZ with your framework, FMX, VCL or WebLib)

MarshalAPI :  ZZZ.SE.RTTK.Marshal is now ZZZ.SERTTK.Marshal

MarshalOptions: ZZZ.SERTTK.MarshalCV is now ZZZ.SERTTK.MarshalTypes

Design Components : ZZZ.SE.RTTK.DT.Marshal is now ZZZ.SERTTK.DT.Marshal

Marshal Options

This release allows access to a global options instance MarshalMV.MarshalOptions , located in ZZZ.SERTTK.MarshalTypes.  You no longer have to create an instance, just use the global instance to update the framework.

Plugin Framework changes

ZZZ.SERTTK.Registry has been consolidated into ZZZ.SERTTK.PluginTypes.  Just remove the reference to the Registry class.

References to RepoComponent need to update to RepoItem.

Logger

ZZZ.SE.Logger changed to ZZZ.SEFNC.Logger

Details

Category: Marshal

Last Updated: 01 May 2023

Marshal provides three options for implementation:

1. Pure Code using an event handler (minimal changes)
2. Marshal Button component (Button as visual component)
3. App Inspector component (Marshal automatically starts with the application)

Read more: Marshal Implementation Options

Details

Category: Marshal

Last Updated: 02 April 2023

implementation

{$R *.dfm}

uses
{$IFDEF DEBUG}
 Vcl.SERTTK.Marshal,
{$ENDIF}
;

procedure TfrmRTTKVCL.btnMarshalClick(Sender: TObject);
begin
{$IFDEF DEBUG}
  TSERTTKMarshalAPI.ShowMarshal;
{$ENDIF}
end;
